KTM 450 SMR [2023-2024] - WÖSSNER forged pistons

WÖSSNER forged pistons for the KTM 450 SMR

The WÖSSNER forged piston is intended for the KTM 450 SMR from the 2023-2024 model year range. As a forged aluminum piston, it offers a precisely defined design for the engine structure. The shaft surface has an anti-friction treatment.

Technical features

• Material: aluminum
• Piston Type: Forged
• Piston compression: standard
• Diameter Ø: 94.95 mm
• Letter oversize: A
• Oversize: STD
• Bore diameter: 95.00 mm
• Compression ratio: 13.5:1
• Rings Quantity: 2
• Stroke: 4T
• Specificity: gas drilling

Suitable for

The piston is assigned to the KTM 450 SMR in the full 2023-2024 model year range. This vehicle assignment supports the selection for the specified model and the specified period.

Scope of delivery

The scope of delivery includes piston rings, circlip and bolts. WÖSSNER forged pistons are manufactured in Germany by specialists in engine parts for 2- and 4-stroke engines. The combination of forged aluminum design, standard piston compression and the specified dimensional data is suitable for the targeted selection of a suitable piston within the specified vehicle assignment.
