KTM 250 SX F [2023-2027] - WÖSSNER forged pistons

✔️ New part
ID: 15712063553862

€265,00 EUR

DELIVERY
Ready to ship | in 2-6 business days
Delivery with DHL in 4-8 business days.
PRODUCT DESCRIPTION

WÖSSNER forged pistons for the KTM 250 SX F

The WÖSSNER forged piston is assigned to the KTM 250 SX F in the 2023-2027 model year range. The forged aluminum design features an anti-friction treatment on the shaft and is designed for standard piston compression.

Technical features

  • Material: aluminum
  • Piston Type: Forged
  • Diameter: 80.97mm
  • Letter oversize: C
  • Oversize: +0.02
  • Bore diameter: 81.02mm
  • Compression ratio: 14.4:1
  • Rings Quantity: 2
  • Stroke: 4T
  • Specificity: Double forged bridge/gas connection

Scope of delivery

The piston includes two piston rings, a circlip and a bolt. This summarizes the components identified for the product and the selection can be checked based on the technical dimensions and markings.

Vehicle assignment

Suitable for: KTM 250 SX F, built between 2023 and 2027.

Wössner forged pistons are manufactured in Germany by specialists in engine parts for 2- and 4-stroke engines. The combination of forged aluminum design, standard piston compression and the specified dimensions supports a targeted assignment for the specified vehicle range.

Description

WÖSSNER forged pistons for the KTM 250 SX F

The WÖSSNER forged piston is assigned to the KTM 250 SX F in the 2023-2027 model year range. The forged aluminum design features an anti-friction treatment on the shaft and is designed for standard piston compression.

Technical features

  • Material: aluminum
  • Piston Type: Forged
  • Diameter: 80.97mm
  • Letter oversize: C
  • Oversize: +0.02
  • Bore diameter: 81.02mm
  • Compression ratio: 14.4:1
  • Rings Quantity: 2
  • Stroke: 4T
  • Specificity: Double forged bridge/gas connection

Scope of delivery

The piston includes two piston rings, a circlip and a bolt. This summarizes the components identified for the product and the selection can be checked based on the technical dimensions and markings.

Vehicle assignment

Suitable for: KTM 250 SX F, built between 2023 and 2027.

Wössner forged pistons are manufactured in Germany by specialists in engine parts for 2- and 4-stroke engines. The combination of forged aluminum design, standard piston compression and the specified dimensions supports a targeted assignment for the specified vehicle range.
