Beta RR 200 2 T [2020-2024] - WÖSSNER forged pistons

WÖSSNER forged pistons for Beta RR 200 2 T

The WÖSSNER forged piston is assigned to the Beta RR 200 2 T in the full year range 2020-2024. As a forged aluminum version, it is designed for use in 2-stroke engines. The anti-friction treatment of the shaft supports a suitable surface base for the operation of the piston in the engine.

Technical features

• Piston Type: Forged
• Material: aluminum
• Piston compression: standard
• Diameter Ø: 61.96 mm
• Letter oversize: B
• Oversize: +0.01
• Bore diameter: 62.01mm
• Piston rings: 2
• Displacement concept: 2T

Scope of delivery and selection

The forged piston includes 2 piston rings, a circlip and a bolt. The information on diameter, oversize and bore diameter makes it easier to compare with the existing engine dimensions. The oversize letter B and +0.01 design should be considered when selecting this piston.

Vehicle assignment

The piston is assigned to the Beta RR 200 2 T for the years 2020-2024. The vehicle and year of manufacture therefore provide a clear basis for selection within this model series.

Manufacturing

Wössner forged pistons are manufactured in Germany by specialists in engine parts for 2- and 4-stroke engines. The combination of forged aluminum design, standard compression and treated piston skirt combines the essential product features of this spare part.
